16. Status Display
356
16.5.3 Selecting the Adjustment Step Resolution
To select the line or sample number adjustment step resolution for when the function dial
(F•D) is turned, follow the procedure below.
Procedure
STATUS → F•2 SDI ANALYSIS → F•1 DATA DUMP → F•2 DUMP OPERATION → F•2 FD
1CLICK: 1 / 10 / 50
16.5.4 Selecting What the Function Dial Controls
To select whether the line number or sample number is controlled with the function dial
(F•D), follow the procedure below. You can also change the line number using the V POS
knob and the sample number using the H POS knob.
Procedure
STATUS → F•2 SDI ANALYSIS → F•1 DATA DUMP → F•2 DUMP OPERATION → F•3 FD
FUNCTION: LINE / SAMPLE
Settings
LINE: Turning the function dial (F•D) changes the line number. If you press the
function dial (F•D), the data of line number 0 or 1 is displayed.
SAMPLE: Turning the function dial (F•D) changes the sample number. If you press
the function dial (F•D), EAV is displayed.
16.5.5 Selecting the Display Mode
To select the data dump display mode, follow the procedure below.
Procedure
STATUS → F•2 SDI ANALYSIS → F•1 DATA DUMP → F•1 MODE: RUN / HOLD
Settings
RUN: The input signal data is automatically updated and displayed.
HOLD: The input signal data is displayed statically.
