14. HDR Display (SER23)
292
14. HDR DISPLAY (SER23)
HDR signals can be measured by installing SER23. HDR signal measurement supports all
formats except for SD and XYZ.
To measure HDR signals, use SYS → F•1 SIGNAL IN OUT → HDR tab to select the HDR signal
standard for each display channel. Also set SYSTEM GAMMA on or off and other settings.
[See also] HDR tab → 7.1.8, “Configuring the HDR Settings (SER23)”
Figure 14-1 HDR tab
