14. HDR Display (SER23)
306
14.3.3 CINEZONE Display
On the CINEZONE display of HDR signals, to display the SDR area in monochrome and HDR
area in color, follow the procedure below to set F•5 HDR ZONE to ON.
If F•5 HDR ZONE is set to ON, STEP and SEARCH cannot be selected for F•1 CINEZONE
FORM.
Procedure
PIC → F•2 CINELITE/HDR → F•5 HDR ZONE: OFF / ON
HDR ZONE = OFF
HDR ZONE = ON
Figure 14-9 CINEZONE display
