Leader LV5300A - Bit Mode

18. Remote Control
428
18.1 Bit Mode
This section describes the control method when Mode on the SYS menu is set to Bit.
• Pinout
Table 18-2 Pinout
Pin No.
Name
I/O (*1)
Description
1
OPEN
-
Open (*2)
2
/P1
I
Loads preset 1
3
/P2
I
Loads preset 2
4
/P3
I
Loads preset 3
5
/P4
I
Loads preset 4
6
/P5
I
Loads preset 5
7
/P6
I
Loads preset 6
8
/P7
I
Loads preset 7
9
/P8
I
Loads preset 8
10
/ACH
I
Selects Ach / Tally1 (*3)
11
/BCH
I
Selects Bch / Tally2 (*3)
12
-
I
-
13
-
I
-
14
ALARM
O
Alarm output
15
GND
-
Ground
*1 Is (inputs) are all pulled up to +3.3 V but can also receive +5 V.
*2 Do not connect anything.
*3 On the REMOTE tab of the SYS menu, when Select is set to Recall, the pins are for Input Select A
and Bch. When Select is set to Recall&Tally, the pins are for Tally 1 and 2.
