5. BEFORE YOU BEGIN MEASURING
61
5.3 Connecting USB Devices
The front panel has two USB ports. You can connect a USB memory device, USB mouse, or
touch panel monitor to these ports. You can connect the devices to either USB port, but you
cannot connect the same type of devices to the instrument simultaneously.
USB devices can be connected or removed with the power turned on.
• USB Memory Device
When a USB memory devices is connected, a USB memory icon appears in the upper
right of the screen.
You can save various types of data in a USB memory device.
This icon is normally green, but it changes to red when the USB memory device is being
accessed. Do not turn the power OFF or remove the USB memory device when the icon is
red.
• USB Mouse
When a USB mouse is connected, a mouse icon appears in the upper right of the screen.
Basic operations can be performed without a mouse, but arranging the measurement screen
layout requires a mouse or touch panel control.
[See also] 6.5, “Customized Layout (SER26),” 6.6, “Enhanced Layout (SER26)”
• Touch Panel Monitor
When the USB touch panel interface of a touch panel monitor is connected, a mouse icon
appears in the upper right of the screen. The video interface of the touch panel monitor is
connected to the monitor output connector.
Basic operations can be performed without a touch panel, but arranging the measurement
screen layout requires a mouse or touch panel control.
[See also] 6.5, “Customized Layout (SER26),” 6.6, “Enhanced Layout (SER26)”
