Leader LV5300A - Data Dump Display Description

16. Status Display
354
16.5.1 Data Dump Display Description
• Detection Code Display
The input signal's embedded ancillary data is detected, and the following detection codes
are displayed.
Table 16-3 Detection code display
Detection
Code
Display
Colors
Description
ADF
Cyan
Ancillary data flags (000h, 3FFh, and 3FFh)
DID
Cyan
Data identification (the data after ADF)
SDID
Cyan
SECONDARY DATA IDENTIFICATION
(the secondary format data when the DID is smaller than 80h)
DBN
Cyan
DATA BLOCK NUMBERS
(the primary data format when the DID is larger than 80h)
DC
Cyan
Data count (the data after the SDID/DBN)
UDW
Cyan
User data words (the user data words of the data count length after
ADF)
CS
Magenta
Checksum (the data immediately after UDW)
AP
Yellow
ACTIVE PICTURE (From after the SAV to just before the EAV
when the selected line is within the active video area)
• Line Number Display
Pictures sent in SDI signals are assigned line numbers as part of the transmission format.
The line number is displayed in one of the following formats at the top of the screen.
Figure 16-4 Line number display
Line number display
Description
LINE No.
The picture scan line numbers and the line numbers during transmission
are matched.
I/F LINE No.
The picture scan line numbers and the line numbers during transmission
are not matched.
Line numbers during transmission are displayed.
PIC LINE No.
The picture scan line numbers and the line numbers during transmission
are not matched.
Picture scan line numbers are displayed.
Normally, the picture scan line numbers and the line numbers for storing those line
numbers during transmission are matched. However, they do not match when the
following format is received.
If this is the case, you can switch between the picture scan line number (PICTURE) and
line numbers during transmission.
Table 16-5 Format
Format
Frame Rate
Switching operation
3G-B-DL
60/59.94/50/48/47.95/P
F•4 DISPLAY (PICTURE/STREAM1/STREAM2)
