16. Status Display
372
16.8.4 Selecting the Dump Mode
To select the dump mode, follow the procedure below.
Procedure
STATUS → F•3 ANC DATA VIEWER → F•1 ANC DUMP → F•3 DUMP MODE: HEX / BINARY
Settings
HEX: Data is displayed in hexadecimal format.
BINARY: Data is displayed in binary format.
DUMP MODE = HEX
DUMP MODE = BINARY
Figure 16-19 Selecting the dump mode
