10. Video Signal Waveform Display
208
10.8.4 Selecting the Setup Level
When F•1 COLOR MATRIX is set to COMPOSITE, to select the setup level, follow the
procedure below.
This menu does not appear if the composite display format is PAL.
Procedure
WFM → F•7 COLOR SYSTEM → F•5 SETUP: 0% / 7.5%
SETUP = 7.5%
Figure 10-29 Selecting the setup level
