11. VECTOR DISPLAY
221
11.6.2 Selecting the Fixed Gain
To select the fixed vector gain, follow the procedure below.
Procedure
VECT → F•3 VECTOR GAIN → F•2 GAIN MAG: X1 / X5 / IQ-MAG
Settings
X1: Vectors are displayed at ×1 magnification.
X5: Vectors are displayed at ×5 magnification.
IQ-MAG: Vectors are displayed using the following magnifications.
×3.12 (for signals other than SD during component display; magnification
that causes the I signal of the multiformat colorbar to lie on the
circumference of the scale)
×2.85 (for signals other than SD during pseudo-composite display;
magnification that causes the I signal of the multiformat colorbar, which
has gone through pseudo-composite conversion, to lie on the
circumference of the scale)
×2.92 (for SD signals during component display; magnification that
causes the amplitude to lie on the circumference of the scale when the
burst signal of the composite vector display is converted into component
signals)
×2.63 (for SD signals during pseudo-composite display; magnification
that causes the -I and Q signals of the SMPTE colorbar, which has gone
through pseudo-composite conversion, to lie on the circumference of the
scale)
When the variable scale is set to on, you cannot select this setting.
11.6.3 Turning the Guide Display On and Off
When the variable scale is set to on and the fixed vector gain is set to X5, to turn the guide
display on and off. When set to on, the current display position is displayed in the upper
right of the screen.
Procedure
VECT → F•3 VECTOR GAIN → F•3 GUIDE DISPLAY: ON / OFF
