8. CAPTURE FEATURE
171
8.4 Displaying Screen Capture Data from a USB Memory Device
To display or overlay on the current input signal the BSG screen capture data that has been
saved to a USB memory device, follow the procedure below.
(Screen capture data that has been saved in BMP format and screen capture data that has
been saved in BSG format on a different model cannot be displayed on the instrument.)
1. Connect a USB memory device to the instrument.
2. Press CAP.
The CAP menu appears.
3. Press F•6 USB MEMORY.
A file list screen and a USB MEMORY menu appear.
4. Press F•5 RECALL.
The BSG format file list screen appears.
5. Turn the function dial (F•D) to select the file that you want to display.
6. Press F•1 RECALL.
The capture data and CAP menu appear.
7. Press F•3 DISPLAY to select the display format.
After you press F•1 RECALL, the display format is BOTH.
8.5 Deleting Screen Capture Data from a USB Memory Device
To delete screen capture data from a USB memory device, follow the procedure below. (You
can also delete the data on the PC.)
1. Connect a USB memory device to the instrument.
2. Press CAP.
The CAP menu appears.
3. Press F•6 USB MEMORY.
A file list screen and a USB MEMORY menu appear.
You can also press F•5 RECALL here to display a BSG format file list screen.
4. Turn the function dial (F•D) to select the file that you want to delete.
