11. VECTOR DISPLAY
219
11.5 Setting the YCbCr Vector Scale (SER40)
When the SER40 is installed and the vector mode is set to YCbCr VECTOR, you can configure
the scale, use F•2 YCbCr VECTOR SCALE on the VECT menu.
VECT → F•2 YCbCr VECTOR SCALE →
Figure 11-10 YCbCr VECTOR SCALE menu
11.5.1 Adjusting the Scale Intensity
To adjust the scale intensity, see section 11.3.1, "Adjusting the Scale Intensity."
11.5.2 Selecting the Scale Color
To select the scale color, see section 11.3.2, "Selecting the Scale Color."
11.5.3 Selecting the Timing Marker
To select the timing marker, follow the procedure below.
Procedure
VECT → F•2 YCbCr VECTOR SCALE → F•3 TIMING MARKER: AUTO / SD / HD
11.5.4 Selecting the YCbCr Vector Scale
To select the scale, see section 11.3.6, "Selecting the Scale."
