16. Status Display
388
16.9.16 Configuring the SCTE-104 Detection Display settings
To display SCTE-104 packets, follow the procedure below.
Procedure
STATUS → F•4 ANC PACKET → F•1 PACKET ANALYSIS → F•4 V-ANC → F•3 SCTE /
CAMERA META → F•1 SCTE-104
• Selecting the Display Format
You can use F•1 DISPLAY to set the display format to TEXT (text display), DUMP (dump
display), or SPLICE (splice display).
If you select TEXT, the text display appears, the currently received packets are displayed
in blue, and they are also recorded as the event log.
If you select DUMP, the dump display appears, and you can turn the function dial (F•D) to
view the entire data. If you press the function dial (F•D), the first entry data is displayed.
If you select SPLICE, the splice display appears, and when a splice_request_data message
is detected, the message appears.
TEXT / DUMP / SPLICE
• Selecting the Text Mode
When F•1 DISPLAY is set to TEXT, you can use F•2 DURTION to select the display time
from 1 to 10 seconds for SCTE-104 packets.
Changing this setting will not change the display time on the SCTE-104 SETUP tab in the
picture display in conjunction.
1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 / 9 / 10
• Updating the dump display
When F•1 DISPLAY is set to DUMP, you can select the update time of the dump display,
follow the procedure below.
Procedure
STATUS → F•4 ANC PACKET → F•1 PACKET ANALYSIS → F•4 V-ANC → F•3 SCTE /
CAMERA META → F•1 SCTE-104 → F•2 HOLD TIME: HOLD / 1s / 3s
Settings
HOLD: Does not update the screen.
1s: Updates the screen every second.
3s: Updates the screen every 3 seconds.
