13. Picture Screen
277
13.6.4 Selecting the Points to Display
You can set three points to measure: P1 to P3. To select the measured points that you want
to display, follow the procedure below.
Procedure
PIC → F•2 CINELITE
→ F•2 f STOP SETUP → F•1 MEASURE NUMBERS: P1 / P1+P2 / P1+P2+P3
→ F•2 %DISPLAY SETUP → F•1 MEASURE NUMBERS: P1 / P1+P2 / P1+P2+P3
Settings
P1: P1 is displayed.
P1+P2: P1 and P2 are displayed.
P1+P2+P3: P1 to P3 are displayed.
13.6.5 Setting Measurement Points
Follow the procedure below to select which measurement point to set with the cursors, and
then move the X cursor by using the H POS knob and the Y cursor by using the V POS knob.
Press the H POS and V POS knobs at the same time to move the cursors to the center of the
picture.
The cursors are not displayed if they are within the blanking interval. To display cursors that
do not appear, move them within the screen.
The measurement point specified for f Stop and that specified for %DISPLAY are linked.
Procedure
PIC → F•2 CINELITE
→ F•2 f STOP SETUP → F•2 MEASURE POSITION: P1 / P2 / P3
→ F•2 %DISPLAY SETUP → F•2 MEASURE POSITION: P1 / P2 / P3
13.6.6 Setting the Measurement Size
To select the measurement size, follow the procedure below. This setting is applied to P1 to
P3 and REF.
The measurement size specified for f Stop and that specified for %DISPLAY are linked.
Procedure
PIC → F•2 CINELITE
→ F•2 f STOP SETUP → F•3 MEASURE SIZE: 1X1 / 3X3 / 9X9
→ F•2 %DISPLAY SETUP → F•3 MEASURE SIZE: 1X1 / 3X3 / 9X9
Settings
1X1: The single pixel at the intersection of the cursors is
measured.
3X3: The 3×3 area of pixels with its center at the intersection
of the cursors is averaged and measured.
9X9: The luminance of the 9×9 area of pixels centered on the
pixel at the intersection of the cursors is averaged and
measured.
