Leader LV5300A - Selecting the Scale; Turning the Variable Scale on and off

11. VECTOR DISPLAY
217
11.3.6 Selecting the Scale
When COLOR MATRIX is set to COMPONENT, follow the procedure below to select the scale
type.
[See also] COLOR MATRIX → section 11.11.1, “Selecting the Color Matrix.”
Procedure
VECT → F•2 VECTOR SCALE → F•3 SCALE OPTION → F•4 VECTOR SCALE: AUTO / BT.601
/ BT.709 / DCI / BT.2020
Settings
AUTO: A scale for the colorimetry selected on the SYS menu is displayed.
BT.601: A scale defined in ITU-R BT.601 is displayed. When the input signal is SD
and a 100 % color bar signal is being applied, the peak levels match the
ends of the scale.
BT.709: A scale defined in ITU-R BT.709 is displayed. When the input signal is HD
and a 100 % color bar signal is being applied, the peak levels match the
ends of the scale.
DCI: A scale defined in DCI is displayed.
BT.2020: A scale defined in ITU-R BT.2020 is displayed. When the input signal is
4K, the division transmission system is 2 sample interleave, and a 100%
color bar signal is being applied, the peak levels match the ends of the
scale.
11.3.7 Turning the Variable Scale On and Off
To turn the variable scale on and off, follow the procedure below. When set to on, the
variable marker display is valid.
When set to on, IQ-MAG cannot be selected for GAIN MAG.
Procedure
VECT → F•2 VECTOR SCALE → F•3 SCALE OPTION → F•5 VARIABLE SCALE: ON / OFF
