19. Network Control
474
19.5.4 Enterprise MIB
• Enterprise Number
The Enterprise Number of LEADER ELECTRONICS CORP. is 20111.
iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).leader(20111)
• Enterprise MIB File
Save the file from instrument to a USB memory device or use FTP to obtain it from the
instrument.
The file name is "lv5300.my."
[See also] 7.2.9, “Configuring SNMP”, 7.2.8, “Configuring the Server”
• Enterprise MIB Structure
The enterprise MIB structure is shown below. On products that do not have units installed,
the MIBs for the units cannot be controlled.
leader OBJECT IDENTIFIER ::= { enterprises 20111 }
lv5300 OBJECT IDENTIFIER ::= { leader 40 }
lv5300ST1 OBJECT IDENTIFIER ::= { lv5300 1 }
l40notificationTBL OBJECT IDENTIFIER ::= { lv5300ST1 0 }
l40basicTBL OBJECT IDENTIFIER ::= { lv5300ST1 1 }
l40systemTBL OBJECT IDENTIFIER ::= { lv5300ST1 2 }
l40wfmTBL OBJECT IDENTIFIER ::= { lv5300ST1 3 }
l40vectorTBL OBJECT IDENTIFIER ::= { lv5300ST1 4 }
l40pictureTBL OBJECT IDENTIFIER ::= { lv5300ST1 5 }
l40statusTBL OBJECT IDENTIFIER ::= { lv5300ST1 6 }
l40eyeTBL OBJECT IDENTIFIER ::= { lv5300ST1 7 }
l40audioTBL OBJECT IDENTIFIER ::= { lv5300ST1 8 }
l40trapTBL OBJECT IDENTIFIER ::= { lv5300ST1 9 }
• ACCESS
In the tables, “ACCESS” indicates the following:
Indication
Description
ACCESS
R/O
Information that can be read from the SNMP managers.
R/W
Information that can be read and written from the SNMP
managers
R/WO
Information that can be read and written from the SNMP
managers
(However, the retrieved data consists of meaningless fixed values.)
