8. CAPTURE FEATURE
169
8.3 Saving to a USB Memory Device
Captured data acquired by pressing CAP is deleted when you perform an operation such as
changing the measurement screen. However, by saving the screen capture data to a USB
memory device in BSG format, you will be able to display the screen capture data on the
instrument even after it is restarted.
Also, if you save the screen capture data in BMP format, you can view the captured data on a
PC.
Use the CAPTURE & DISPLAY tab on the SYS menu to set the file format.
[See also] CAPTURE & DISPLAY tab → 7.2.4, “Configuring the Capture Feature”
1. Connect a USB memory device to the instrument.
2. Press F•6 USB MEMORY.
A file list screen and a USB MEMORY menu appear.
3. Select how to name the file.
If F•1 AUTO FILENAME is set to on, the file is automatically assigned a name that consists
of the year, month, day, hour, minute, and second (in that order) that are set on the SYS
menu. (Example: 20090501100859.bmp)
Screen capture data is saved to the following locations.
USB memory device
└ LV5300_USER, LV5350_USER or LV7300_USER
└ BMP
├ yyyymmddhhmmss.bmp
└ yyyymmddhhmmss.bsg
