10.4.4 Setting the Scale Jump
If F•2 GAIN MAG is set to X5, the waveform is expanded five times in the Y-axis direction.
To select the area you want to see expanded, follow the procedure below. You can view the
area that is currently displayed with respect to the entire waveform on the scale shown on
the right side of the screen.
This menu item appears when GAIN MAG is set to X5 or X10.
Procedure
WFM → F•2 GAIN/FILTER → F•5 SCALE JUMP: 0% / 10% / 20% / 30% / 40% / 50% /
60% / 70% / 80% / 90% / 100% / CURSOR
• 0 to 100%
The instrument has 11 types of screens in the Y-axis direction, these screens are switched
in the range of 0 to 100%.
For example, if the scale unit is % and YCbCr is displayed, selecting 0% displays the 0 to
20% range, selecting 10% displays the 10 to 30% range, selecting 90% displays the 90 to
110% range, and selecting 100% displays the 100 to 120% range.
