10. Video Signal Waveform Display
203
CURSOR VALUE = ON
Figure 10-23 Turning the cursor value display on and off
10.7 Configuring the Line Selection Settings
To configure the line selection settings, press F•5 LINE SELECT on the WFM menu.
WFM → F•5 LINE SELECT →
Figure 10-24 LINE SELECT menu
10.7.1 Turning Line Selection On and Off
To display the vector of the selected line, follow the procedure below. You can use the
function dial (F•D) to select a line. The number of the selected line appears in the lower left
of the screen.
Changing this setting will also change the vector-display and picture-display line selection
settings.
When SWEEP is set to V, this is fixed at OFF.
When CINELITE ADVANCE is set to on, CINELITE appears.
[See also] SWEEP → 10.5.1, “Selecting the Sweep Method,”
CINELITE ADVANCE → 13.6.8, “Displaying Link Markers”
Procedure
WFM → F•5 LINE SELECT → F•1 LINE SELECT: ON / OFF / CINELITE
