3. SPECIFICATIONS
18
3.3.5 External Reference Input
Connector Type BNC
Number of Input Connectors 1 pair
Input Impedance 15 kΩ passive loop-through
Input Return Loss ≥ 30 dB for 50 kHz to 30 MHz into 75 Ω
Maximum Input Voltage ±5 V (DC + peak AC)
Input Signal Tri-level sync or NTSC/PAL black burst signal
Function Video signal waveform display and phase difference display
based on the phase of an external sync signal
* The display position of the video signal waveform display and the measured phase of the phase
difference display based on the phase of the external sync signal may vary by ±1 clock depending
on the timing when the external sync signal or SDI signal is connected or disconnected or when
the device is restarted.
* Video signal waveform display based on the phase of an external sync signal is not possible for the
following formats.
• 3G’s 720/30P, 720/29.97P, 720/25P, 720/24P, 720/23.98P
• 3G(DL), 6G, 12G
• Frame frequency 48P, 47.95P
* Phase difference display based on the phase of an external sync signal is not possible for the
following formats.
• 3G’s 720/30P, 720/29.97P, 720/25P, 720/24P, 720/23.98P
• Frame frequency 48P, 47.95P
3.3.6 Monitor Output Connector (LV7300)
SDI Output Connector
Function Output the displayed screen to an SDI monitor
Output Connector BNC
Number of Output Connectors
1
Output Impedance 75Ω
Output Return Loss
5 MHz to 1.485 GHz 15 dB or more
1.485 to 2.97 GHz 10 dB or more
Output Voltage 800 mVp-p ± 10 % (into 75 Ω)
Output Signal Outputs the LCD screen in HD, 3G-A, or 3G-B-DL.
Output Format
Color System
Quantization
Frame (Field) Frequency/Scanning
Supported Standard
YC
B
C
R
4:2:2
10 bit
1920×1080
60/59.94/50 /I
24/23.98 /PsF (*1)
SMPTE ST 274
60/59.94/50/48/47.95 /P
Synchronization Synchronized with the LCD refresh rate (free run)
