13. Picture Screen
258
13.4.1 Turning the Frame Marker On and Off
To turn the frame marker on and off, follow the procedure below.
Procedure
PIC → F•1 PIC CONFIG → F•4 MARKER → F•1 FRAME MARKER: ON / OFF
13.4.2 Turning the Center Marker On and Off
To turn the center marker on and off, follow the procedure below.
Procedure
PIC → F•1 PIC CONFIG → F•4 MARKER → F•2 CENTER MARKER: ON / OFF
13.4.3 Setting the Aspect Marker
To display the aspect marker, follow the procedure below.
Procedure
PIC → F•1 PIC CONFIG → F•4 MARKER → F•3 ASPECT MARKER: OFF / 17:9 / 16:9 / 14:9 /
13:9 / 4:3 / 2.39:1 / AFD
Settings
OFF: The aspect marker is not displayed.
17:9 A 17:9 aspect marker is displayed.
This option cannot be selected when the input signal is a 17:9 frame
signal or an SD signal.
16:9: A 16:9 aspect marker is displayed.
This option cannot be selected when the input signal is a 16:9 frame
signal.
14:9: A 14:9 aspect marker is displayed.
13:9: A 13:9 aspect marker is displayed.
4:3: A 4:3 aspect marker is displayed.
This option cannot be selected when the input signal is SD.
2.39:1: A 2.39:1 aspect marker is displayed.
This option cannot be selected when the input signal is SD.
AFD: The aspect marker included in the AFD (Active Format Description)
packets is displayed. Also, abbreviations for SMPTE ST 2016-1-2007
standard AFD codes are displayed in the upper left of the screen.
This option can be selected when the input signal is SD or HD.
