13. Picture Screen
259
The AFD codes that are displayed in the upper left of the screen are displayed as shown
below according to the coded frame and the AFD code. If there are no AFD packets
embedded in the input signal, “---------” is displayed.
Table 13-1 AFD display
Displayed
Abbreviation
Coded
Frame
AFD
Code
Description
0000- UNDEFINED
0 (4:3)
0000
Undefined
0001- RESERVED
0 (4:3)
0001
Reserved
0010- 16:9LBTop
0 (4:3)
0010
Letterbox 16:9 image, at top of the coded frame
0011- 14:9LBTop
0 (4:3)
0011
Letterbox 14:9 image, at top of the coded frame
0100- >16:9LBox
0 (4:3)
0100
Letterbox image with an aspect ratio greater than
16:9, vertically centered in the coded frame
0101- RESERVED
0 (4:3)
0101
Reserved
0110- RESERVED
0 (4:3)
0110
Reserved
0111- RESERVED
0 (4:3)
0111
Reserved
1000- FullFrame
0 (4:3)
1000
Full frame 4:3 image, the same as the coded frame
1001- Full Frame
0 (4:3)
1001
Full frame 4:3 image, the same as the coded frame
1010- 16:9LBox
0 (4:3)
1010
Letterbox 16:9 image, vertically centered in the
coded frame with all image areas protected
1011- 14:9LBox
0 (4:3)
1011
Letterbox 14:9 image, vertically centered in the
coded frame
1100- RESERVED
0 (4:3)
1100
Reserved
1101-4:3Full14:9
0 (4:3)
1101
Full frame 4:3 image, with alternative 14:9 center
1110-16:9LB14:9
0 (4:3)
1110
Letterbox 16:9 image, with alternative 14:9 center
1111-16:9LB4:3
0 (4:3)
1111
Letterbox 16:9 image, with alternative 4:3 center
0000w UNDEFINED
1 (16:9)
0000
Undefined
0001w RESERVED
1 (16:9)
0001
Reserved
0010w Full Frame
1 (16:9)
0010
Full frame 16:9 image, the same as the coded frame
0011w 14:9Pillbox
1 (16:9)
0011
Pillarbox 14:9 image, horizontally centered in the
coded frame
0100w >16:9LBox
1 (16:9)
0100
Letterbox image with an aspect ratio greater than
16:9, vertically centered in the coded frame
0101w RESERVED
1 (16:9)
0101
Reserved
0110w RESERVED
1 (16:9)
0110
Reserved
0111w RESERVED
1 (16:9)
0111
Reserved
1000w FullFrame
1 (16:9)
1000
Full frame 16:9 image, the same as the coded frame
1001w 4:3Pillbox
1 (16:9)
1001
Pillarbox 4:3 image, horizontally centered in the
coded frame
1010w FullNoCrop
1 (16:9)
1010
Full frame 16:9 image, with all image areas protected
1011w14:9Pillbox
1 (16:9)
1011
Pillarbox 14:9 image, horizontally centered in the
coded frame
1100w RESERVED
1 (16:9)
1100
Reserved
1101w4:3PB14:9
1 (16:9)
1101
Pillarbox 4:3 image, with alternative 14:9 center
1110wFul14:9Safe
1 (16:9)
1110
Full frame 16:9 image, with alternative 14:9 center
1111wFull4:3Safe
1 (16:9)
1111
Full frame 16:9 image, with alternative 4:3 center
