19. Network Control
475
• l40basicTBL(1) group
MIB
OID
SYNTAX
ACCESS
VALUE/RANGE
l40basInputTBL
l40basicTBL.1
Aggregate
-
-
l40basInputCh
l40basInputTBL.1
INTEGER
R/W
1 = a
2 = b
l40basInputSimul
l40basInputTBL.2
INTEGER
R/W
1 = off
2 = on
l40basInputOperate
l40basInputTBL.3
INTEGER
R/W
1 = com
2 = individual
l40basInputExtref
l40basInputTBL.4
INTEGER
R/W
1 = int
2 = ext
l40basDispTBL
l40basicTBL.3
Aggregate
-
-
l40basDispMulti
l40basDispTBL.1
INTEGER
R/WO
1 (fixed)
l40basDispAssignWfm
l40basDispTBL.2
INTEGER
R/WO
1 (fixed)
l40basDispAssignVec
l40basDispTBL.3
INTEGER
R/WO
1 (fixed)
l40basDispAssignPic
l40basDispTBL.4
INTEGER
R/WO
1 (fixed)
l40basDispAssignSts
l40basDispTBL.5
INTEGER
R/WO
1 (fixed)
l40basDispAssignEye
l40basDispTBL.6
INTEGER
R/WO
1 (fixed)
l40basDispAssignAud
l40basDispTBL.7
INTEGER
R/WO
1 (fixed)
l40basPresetTBL
l40basicTBL.4
Aggregate
-
-
l40basPresetStore
l40basPresetTBL.1
INTEGER
R/W
1 to 60
l40basPresetDelete
l40basPresetTBL.2
INTEGER
R/W
1 to 60
l40basPresetCopyUsbInt
l40basPresetTBL.3
INTEGER
R/WO
1 (fixed)
l40basPresetCopyIntUsb
l40basPresetTBL.4
INTEGER
R/WO
1 (fixed)
l40basPresetRecall
l40basPresetTBL.5
INTEGER
R/W
1 to 60
l40basCaptureTBL
l40basicTBL.5
Aggregate
-
-
l40basCaptureMode
l40basCaptureTBL.1
INTEGER
R/W
1 = screen
l40basCaptureRefresh
l40basCaptureTBL.3
INTEGER
R/WO
1 (fixed)
l40basCaptureDisplay
l40basCaptureTBL.4
INTEGER
R/W
1 = real
3 = both
4 = hold
l40basCaptureFileBmp
l40basCaptureTBL.5
INTEGER
R/W
1 = off
2 = on
l40basCaptureFileBsg
l40basCaptureTBL.6
INTEGER
R/W
1 = off
2 = on
l40basCaptureFileStore
l40basCaptureTBL.10
INTEGER
R/WO
1 (fixed)
l40basMakeTBL
l40basicTBL.6
Aggregate
-
-
l40basMakeFile
l40basMakeTBL.1
INTEGER
R/WO
1 = cap-bmp
2 = cap-bsg
15 = log (*1)
16 = dump (*1)
*1 If you want to create an event log, data dump, or loudness file, the corresponding measurement
screen must be displayed on the screen.
• l40systemTBL(2) group
MIB
OID
SYNTAX
ACCESS
VALUE/RANGE
l40sysInputTBL
l40systemTBL.1
Aggregate
-
-
l40sysSdiIn
l40sysInputTBL.1
INTEGER
R/W
2 = sys-4k-3g-dlink
4 = sys-single-link
8 = sys-4k-12g
9 = sys-4k-6g
l40sysSdiColorimetry
l40sysInputTBL.2
INTEGER
R/W
1 = pid
2 = bt709
3 = bt2020
4 = dci
l40sysHdrTBL
l40systemTBL.4
Aggregate
-
-
