14. HDR Display (SER23)
293
• Scale Unit and Range
The scale unit and range used on HDR signal measurements are as follows depending on the
settings on the HDR tab.
HDR Mode
EI
System
Gamma
Range
HLG
Scale
Scale
OFF
-
-
-
-
None
HLG
-
OFF
Narrow
1200%
SDI code value: 64 to 940 is displayed as 0 to 1200%.
100%
SDI code value: 64 to 940 is displayed as 0 to 100%.
Full
1200%
SDI code value: 0 to 1023 is displayed as 0 to 1200%. (*1)
100%
SDI code value: 0 to 1023 is displayed as 0 to 100%. (*1)
ON
Narrow
1200%
SDI code value: 64 to 940 is displayed as 0 to 1000Nits.
100%
SDI code value: 64 to 940 is displayed as 0 to 1000Nits.
Full
1200%
SDI code value: 0 to 1023 is displayed as 0 to 1000Nits.
(*1)
100%
SDI code value: 0 to 1023 is displayed as 0 to 1000Nits.
(*1)
PQ
-
-
Narrow
-
SDI code value: 64 to 940 is displayed as 0 to 10000Nits.
Full
-
SDI code value: 0 to 1023 is displayed as 0 to 10000Nits.
(*1)
S-Log3
-
OFF
-
-
SDI code value: 95 to 940 is displayed as 0 to 2055%.
ON
-
-
SDI code value: 95 to 940 is displayed as 0 to 3000Nits.
C-Log
-
-
-
-
Displays the percentage with the SDI code value 128
assumed to 0% and 614 assumed to be 100%
Log-C
200
-
-
-
Displays the percentage with the SDI code value 95
assumed to 0.39% and 853 assumed to be 83%
400
-
-
-
Displays the percentage with the SDI code value 95
assumed to 0.39% and 917 assumed to be 90%
800
-
-
-
Displays the percentage with the SDI code value 95
assumed to 0.39% and 976 assumed to be 95%
1600
-
-
-
Displays the percentage with the SDI code value 95
assumed to 0.39% and 1022 assumed to be 94%
PayloadID
UnSpec:S-Log3
Operates in OFF (SDR-TV), HLG, or PQ mode according to the payload ID information. When the
payload ID information is Unspecified, the instrument operates in S-Log3 mode.
PayloadID
UnSpec:C-Log
Operates in OFF (SDR-TV), HLG, or PQ mode according to the payload ID information. When the
payload ID information is Unspecified, the instrument operates in C-Log mode.
PayloadID
UnSpec:Log-C
Operates in OFF (SDR-TV), HLG, or PQ mode according to the payload ID information. When the
payload ID information is Unspecified, the instrument operates in Log-C mode.
*1 SDI code values: 0 to 1023 take on values from 4 to 1019.
