19. Network Control
443
• VECTOR KEY
r/w
Limitation
Command
Parameter
WO
VECTOR
None
-
WFM:COLOR
WHITE / YELLOW / CYAN / GREEN / MAGENTA /
RED / BLUE / MULTI / ?
-
WFM:SCALE:INTEN
-8 to 7 / ?
-
WFM:SCALE:COLOR
WHITE / YELLOW / CYAN / GREEN / MAGENTA /
RED / BLUE / ?
-
WFM:SCALE:UNIT
HDV_SDP / HDV_SDV / HDP_SDP / CV_DEC /
CV_HEX / ?
-
WFM:SCALE:UNIT:NTSC
P / ?
-
WFM:SCALE:UNIT:PAL
V / ?
-
WFM:SCALE:UNIT:FULL
HDP_SDP / CV_DEC / CV_HEX / ?
-
WFM:SCALE:75_COLOR
ON / OFF / ?
-
WFM:SCALE:DISPLAY
ON / OFF / BOTH / MAIN / HDR / ?
-
WFM:GAIN:VARIABLE
CAL / VAR / ?
-
WFM:GAIN:MAG
X1 / X5 / X10 / ?
-
WFM:GAIN:VALUE
20 to 200 / ?
* MAG value × 0.200 (20) - 2.000 (200)
-
WFM:GAIN:SCALE_JUMP
0P / 10P / 20P / 30P / 40P / 50P / 60P / 70P / 80P
/ 90P / 100P / CURSOR / ?
-
WFM:FILTER:NORMAL
FLAT / LOWPASS / ?
-
WFM:FILTER:COMPOSITE
FLAT / LUM / FLAT_LUM / LUM_CRMA / ?
-
WFM:SWEEP
H / V / ?
-
WFM:SWEEP:H_SWEEP
1H / 2H / ?
-
WFM:SWEEP:V_SWEEP
1V / 2V / ?
-
WFM:SWEEP:H_MAG
X1 / X10 / X20 / ACTIVE / BLANK / ?
-
WFM:SWEEP:V_MAG
X1 / X20 / X40 / ?
-
WFM:SWEEP:FIELD
FIELD1 / FIELD2 / ?
-
WFM:BLANKING:NORMAL
REMOVE / H_VIEW / V_VIEW / ALL_VIEW / ?
-
WFM:BLANKING:COMPOSITE
REMOVE / V_VIEW / ?
-
WFM:CURSOR
SINGLE / BOTH / OFF / ?
-
WFM:CURSOR:SELECT
X / Y / ?
-
WFM:CURSOR:UNIT:X
SEC / HZ / ?
-
WFM:CURSOR:UNIT:Y
MV / P / RP / DEC / HEX / HDR / ?
-
WFM:CURSOR:UNIT:Y:COMPOSITE
MV / P / RP / ?
-
WFM:CURSOR:FD
REF / DELTA / TRACK / ?
-
WFM:CURSOR:REF
0 to 927 (when X is selected)
-5000 to 15000 (when Y is selected)
-
WFM:CURSOR:DELTA
0 to 927 (when X is selected)
-5000 to 15000 (when Y is selected)
-
WFM:CURSOR:TRACK
0 to 927 (when X is selected)
-5000 to 15000 (when Y is selected)
WO
WFM:CURSOR:REFSET
None
-
WFM:CURSOR:VAL
ON / OFF / ?
-
WFM:LINE_SELECT
ON / OFF / CINELITE / ?
-
WFM:LINE_NUMBER
0 to 32767 / ?
-
WFM:LINE_FIELD
FIELD1 / FIELD2 / FRAME / ?
-
WFM:MATRIX:YCBCR
YCBCR / GBR / RGB / COMPOSITE / ?
-
WFM:MATRIX:RGB
GBR / RGB / COMPOSITE / ?
-
WFM:MATRIX:YGBR
ON / OFF / ?
-
WFM:MATRIX:YRGB
ON / OFF / ?
-
WFM:MATRIX:COMPOSITE:FORMAT
AUTO / NTSC / PAL / ?
-
WFM:MATRIX:COMPOSITE:SETUP
0P / 7.5P / ?
-
WFM:MATRIX:XYZ
XYZ / GBR / RGB / COMPOSITE / ?
