19. Network Control
444
-
VECTOR:DISPLAY
VECT / 5BAR / HIST / CIE / ?
-
VECTOR:LINE_SELECT
ON / OFF / CINELITE / ?
-
VECTOR:LINE_NUMBER
0 to 32767 / ?
-
VECTOR:LINE_FIELD
FIELD1 / FIELD2 / FRAME / ?
-
VECTOR:MATRIX:CB
100P / 75P / ?
-
VECTOR:MATRIX:COLOR_MATRIX
COMPONENT / COMPOSITE / ?
-
VECTOR:MATRIX:COMPOSITE:FORMAT
AUTO / NTSC / PAL / ?
-
VECTOR:MATRIX:COMPOSITE:SETUP
0P / 7_5P / ?
-
VECTOR:VECTOR:MODE
VECTOR / RGBVECTOR / YCBCRVECTOR / ?
-
VECTOR:VECTOR:INTEN
-128 to 127 / ?
-
VECTOR:VECTOR:COLOR
WHITE / YELLOW / CYAN / GREEN / MAGENTA /
RED / BLUE / ?
-
VECTOR:VECTOR:SCALE:INTEN
-8 to 7 / ?
-
VECTOR:VECTOR:SCALE:COLOR
WHITE / YELLOW / CYAN / GREEN / MAGENTA /
RED / BLUE / ?
-
VECTOR:VECTOR:SCALE:IQ_AXIS
ON / OFF / ?
-
VECTOR:VECTOR:SCALE:VEC_SCALE
AUTO / BT601 / BT709 / BT2020 / DCI / ?
-
VECTOR:VECTOR:SCALE:VAR_SCALE
ON / OFF / ?
-
VECTOR:VECTOR:GAIN:VARIABLE
CAL / VAR / ?
-
VECTOR:VECTOR:GAIN:MAG
X1 / X5 / IQ / ?
-
VECTOR:VECTOR:GAIN:VALUE
200 to 2000 / ?
* X1
1000 to 10000 / ?
* X5
580 to 5840 / ?
* IQ-MAG or SD, composite display
620 to 6240 / ?
* not IQ-MAG or SD, component display
520 to 5260 / ?
* IQ-MAG or SD, for pseudo-composite display
570 to 5700 / ?
* not IQ-MAG or SD, for pseudo-composite display
-
VECTOR:GAIN:GUIDE_DISP
ON / OFF / ?
-
VECTOR:VECTOR:MARKER
ON / OFF / ?
-
VECTOR:VECTOR:VAR_MKR:MKR_SIZE
5 to 10 / ?
-
VECTOR:RGBVECTOR:SCALE:ADJ_TARGET
GB / GR / ?
-
VECTOR:RGBVECTOR:SCALE:H
-500 to 500 / ?
-
VECTOR:RGBVECTOR:SCALE:V
-500 to 500 / ?
-
VECTOR:RGBVECTOR:GAIN:H
200 to 2000 / ?
* 0.200 (200) - 2.000 (2000)
-
VECTOR:RGBVECTOR:GAIN:V
200 to 2000 / ?
* 0.200 (200) - 2.000 (2000)
-
VECTOR:YCBCRVECTOR:SCALE:TIM_MKR
AUTO / HD / SD / ?
-
VECTOR:YCBCRVECTOR:SCALE:VEC_SCALE
AUTO / BT601 / BT709 / BT2020 / DCI / ?
-
VECTOR:YCBCRVECTOR:GAIN:VARIABLE
CAL / VAR / ?
-
VECTOR:YCBCRVECTOR:GAIN:MAG
X1 / X5 / ?
-
VECTOR:YCBCRVECTOR:GAIN:VALUE
200 to 2000 / ?
* MAG value × 0.200 (200) - 2.000 (2000)
-
VECTOR:YCBCRVECTOR:GAIN:OBS_POINT
BY_WH / BY_YL / BY_CY / BY_G / BY_TM / BY_MG
/ BY_R / BY_B / BL / RY_B / RY_R / RY_MG /
RY_TM / RY_G / RY_CY / RY_YL / RY_WH / ?
RO
VECTOR:5BAR:Y:DATA
?
RO
VECTOR:5BAR:G:DATA
?
RO
VECTOR:5BAR:B:DATA
?
RO
VECTOR:5BAR:R:DATA
?
RO
VECTOR:5BAR:CMP:DATA
?
-
VECTOR:5BAR:SCALE
P / MV / HEX / DEC / ?
-
VECTOR:5BAR:SEQUENCE
GBR / RGB / ?
