7. SYSTEM SETTINGS
131
• System
• Structure
• Frame/Field Rate
When format alarm detection is on, specify the expected format. For information on the
format combinations that are available, see section 3.3.1, “SDI Video Formats and
Standards.”
Table 7-2 Format selection
Video System
System
Structure
Frame/Field Rate
Division
4K 12G
3840x2160 12G
4096x2160 12G
YCbCr(422) 10bit
YCbCr(422) 12bit
YCbCr(444) 10bit
YCbCr(444) 12bit
RGB(444) 10bit
RGB(444) 12bit
60/59.94/50/48/47.95/
30/29.97/25/24/23.98/P
-
4K 6G
3840x2160 6G
4096x2160 6G
YCbCr(422) 10bit
30/29.97/25/24/23.98/P
-
4K 3G Dual Link
3840x2160 3G-B DS Dual
4096x2160 3G-B DS Dual
YCbCr(422) 10bit
30/29.97/25/24/23.98/P
30/29.97/25/24/23.98/PsF
Square/
2 Sample
Interleave
SD/HD/3G-A/3G-B-DL
1920x1080 3G-B-DL
2048x1080 3G-B-DL
1280x720 3G-A
1920x1080 3G-A
2048x1080 3G-A
1280x720 HD
1920x1080 HD
720x487 SD
720x576 SD
YCbCr(422) 10bit
YCbCr(422) 12bit
YCbCr(444) 10bit
YCbCr(444) 12bit
RGB(444) 10bit
RGB(444) 12bit
XYZ(444) 12bit
60/59.94/50/I
60/59.94/50/48/47.95/
30/29.97/25/24/23.98/P
30/29.97/25/24/23.98/PsF
-
• Colorimetry
Turn on and off the colorimetry alarm detection.
Normally, colorimetry is displayed in cyan on the vector waveform display and CIE
chromaticity diagram display. But for 3G(DL)-4K, if any of the colorimetries does not
match, it is displayed in yellow.
If alarm detection is set to on and a colorimetry other than that specified with Type is
received, the colorimetry is displayed in red. It is also displayed in red on the video signal
waveform display.
Note that this is invalid when the input signal is SD.
OFF / ON
• Type
When colorimetry alarm detection is on, specify the expected colorimetry.
BT-709 / BT-2020 / DCI
