• Pattern
• Interlock
Select the output pattern. The selectable patterns are shown below. The selectable
patterns vary depending on the System setting.
Depending on the pattern, you can turn on and off YCbCr or RGB separately.
For COLOR RASTER, you can set the YCbCr or RGB levels separately. Moreover, if
Structure is set to RGB, you can select the Interlock check box to synchronize the RGB
levels.
Table 7-4 Output pattern selection
Pattern
YCbCr/RGB on/off
Level adjustment
COLOR BAR 100%
Yes
No
COLOR BAR 75%
Yes
No
ARIB2020 COLOR BAR (*1)
Yes
No
MULTI COLOR BAR 100% (*1)
Yes
No
MULTI COLOR BAR 75% (*1)
Yes
No
MULTI COLOR BAR (+I) (*1)
Yes
No
COLOR RASTER
Yes
Yes
OETF
Yes
No
CROSS HATCH
Yes
No
10_STEP
Yes
No
LIMIT RAMP
Yes
No
CHECK FIELD
No
No
LIP SYNC (SER20)
No
No
HDR COLOR BAR (SER23) (*1)
Yes
No
* The signal will be interrupted when the pattern is changed.
*1 It cannot be set in horizontal 1280, 2048, and 4096 pixel format.
When OETF is selected, select the gamma characteristics.
BT-709 / HLG / PQ
Note that bandwidth limit is not applied to patterns other than COLOR BAR 100% and
COLOR BAR 75%.
