7. SYSTEM SETTINGS
136
• Embedded Audio
When the pattern is not LIP SYNC, select the audio channels to embed in the SDI signal.
1 to 4ch is referred to as G1, 5 to 8ch as G2, 9 to 12ch as G3, and 13 to 16ch as G4.
The channels that can be embedded are 8 channels or 16 channels depending on the
system and frame/field rate as shown below.
Table 7-5 Embedded audio settings
System
Frame/Field Rate
G1
G2
G3
G4
3840x2160 12G
4096x2160 12G
3840x2160 6G
1920x1080 3G-B-DL
1920x1080 3G-A
2048x1080 3G-A
1920x1080 HD
1280x720 HD
-
Yes
Yes
Yes
Yes
4096x2160 6G
-
Yes
Yes
No
No
2048x1080 3G-B-DL
60/59.94/30/29.97/P
30/29.97/PsF
Yes
Yes
No
No
50/48/47.95/25/24/23.98/P
25/24/23.98/PsF
Yes
Yes
Yes
Yes
• Level
Select the embedded audio level.
-20dBFS / -18dBFS / 0dBFS / Mute
• CRC Error
When set to on, an incorrect CRC is inserted into the Y component of the first line.
OFF / ON
