7. SYSTEM SETTINGS
158
• FILTER
Set the filter and display order to apply when the FILTER key is pressed in the pseudo-
composite display of the video signal waveform display. Select SKIP to skip an item.
Note that for component display, the FILTER key is used to switch between FLAT and
LOWPASS.
FLAT / LUM / FLAT+LUM / LUM+CRMA / SKIP
• MAG(GAIN)
Set the magnification and display order to apply when the MAG (GAIN) key is pressed on
the video signal waveform display or vector display. Select SKIP to skip an item.
WFM: X1 / X5 0% / X5 10% / X5 20% / X5 30% / X5 40% / X5 50% / X5
60% / X5 70% / X5 80% / X5 90% / X5 100% / X10 0% / X10 10% /
X10 20% / X10 30% / X10 40% / X10 50% / X10 60% / X10 70% /
X10 80% / X10 90% / X10 100% / SKIP
VECTOR: X1 / X5 / IQ-MAG / SKIP
• SWEEP
Set the sweep method and display order to apply when the SWEEP key is pressed on the
video signal waveform display. Select SKIP to skip an item.
1H / 2H / 1V / 2V / SKIP
• MAG(SWEEP)
Set the horizontal magnification and display order to apply when the MAG (SWEEP) key is
pressed on the video signal waveform display. Select SKIP to skip an item.
X1 / X10 / X20 / X40 / ACTIVE / BLANK / SKIP
