1. INTRODUCTION
4
• Input Formats and Link Systems
The following names are used for the input formats and link systems.
Multi link may be used as a collective term to refer to dual link and quad link.
Table 1-3 Input formats and link systems
Name
Description
Link System
SD
SD-SDI
Single link
HD
HD-SDI
Single link
3G-A
3G-SDI level A
Single link
3G-B-DL
3G-SDI level B dual link mapping
Single link
6G
6G-SDI
Single link
12G
12G-SDI
Single link
3G(DL)-4K
3G-B DS dual link
Resolution 3840 (4096)×2160
Dual link
3G
Collective name for 3G links
-
3G-B
Collective name for 3G-B-DL and 3G-B DS
-
3G(DL)
Collective name for 3G(DL)-2K, 3G(DL)-4K
-
2K
Collective name for SD, HD, 3G-A, 3G-B-DL
-
4K
Collective name for 6G, 12G
-
