10. Video Signal Waveform Display
197
Settings
X1: The video signal waveforms are displayed so that they fit on the screen.
X10: The video signal waveforms are magnified from the center of the display
to 10 times the size of X1.
X20: The video signal waveforms are magnified from the center of the display
to 20 times the size of X1.
X40: The video signal waveforms are magnified from the center of the display
to 40 times the size of X1.
ACTIVE: Everything but the video signal waveform blanking interval is magnified.
BLANK: The video signal waveform blanking interval is magnified.
The vertical blanking interval is also displayed on the vector display.
SWEEP MAG = X1
SWEEP MAG = X10
