13. Picture Screen
282
Keyword
Be sure to put the keyword lines before the data lines and to enter a keyword without
anything preceding it at the beginning of each keyword line.
NAME: The instrument displays the eight characters that follow the separator
(colon) as the name of the correction table. After the separator, enter
the correction table name using letters of the alphabet (A to Z;
uppercase and lowercase), numbers (0 to 9), and underscores (_).
You can enter up to 10 characters.
TYPE: This is a code for identifying the file type. Enter a zero after the
separator (colon).
Data
From the start of a line, enter the input value, a separator, and then the output value, in
that order.
Input value: Enter values from 0 to 4095 (12 bits), increasing the value by one for
each line.
A luminance level of 100 % is defined as 940 (10 bits) × 4 = 3760
(12 bits).
A luminance level of 0 % is defined as 64 (10 bits) × 4 = 256 (12
bits).
Separator: Enter a single tab code.
Output value: Enter a value from 0 to 65535 (16 bits).
2. Save the user-defined correction table to USB memory, and connect the USB memory to
the instrument.
Save the correction table in the following directory.
USB memory device
└ LV5300_USER, LV5350_USER or LV7300_USER
└ CLT
└ TEST.CLT (example)
3. Press PIC.
4. Press F•2 CINELITE.
5. Press F•1 CINELITE DISPLAY to select f Stop.
6. Press F•2 f STOP SETUP.
7. Press F•5 GAMMA and then F•1 GAMMA SELECT to select USER_A.
In this example, a user-defined correction table is copied to USER_A, but user-defined
correction tables can be copied to USER_B through USER_E in the same way.
8. Press F•2 GAMMA FILE.
This setting is available when F•1 GAMMA SELECT is set to an option from USER_A to
USER_E.
9. Press F•1 FILE LIST.
The file list screen appears. This setting appears when a USB memory device is
connected.
To clear the table that has been copied to USER_A, press F•2 TABLE CLEAR.
