16. Status Display
335
• Inhibit
An error is counted when embedded audio packets are found in lines where they should
not be embedded. The embedding inhibit lines are as follows.
However, for 3G-B-DL 60p, 59.94p, 50p, 48p, and 47.95p, the transmission scanning
mode is interlace. For 12G and 6G, the line numbers are those of the sub images divided
into the HD and 3G data structure.
Table 16-1 Embedding inhibit lines
• Audio Sample
An error is counted when audio that is asynchronous to the video is embedded. For the
video and audio to be synchronized, there is a specific number of audio data samples that
need to be embedded in a given number of video frames. If this rule is not met, it is
considered an error.
• Freeze
An error is counted when the video data is the same between video frames. Specify an
area of the video to use for detection and the number of continuous frames that is
required for the condition to be detected as an error.
Video data is compared using checksums.
• Black
An error is counted when the video luminance level is less than the specified value.
Set the luminance level for detecting error pixels, the ratio of error pixels in a frame, and
the number of continuous frames that is required for the condition to be detected as an
error.
• Gamut
Gamut errors are counted.
Set the upper and lower limits for detecting errors, the ratio of error pixels in a frame, and
the number of continuous frames that is required for the condition to be detected as an
error.
• Comp Gamut
Composite gamut errors are counted.
Set the upper and lower limits for detecting errors, the ratio of error pixels in a frame, and
the number of continuous frames that is required for the condition to be detected as an
error.
• Level Y
An error is counted when the luminance level is outside the specified range.
Set the upper and lower limits for detecting errors.
