16. Status Display
338
• CRC Error(Except SD)
Select whether to detect CRC errors. This setting is valid when the input signal is not SD.
OFF / ON
• EDH Error(SD)
Select whether to detect EDH errors. This setting is valid when the input signal is SD.
OFF / ON
• Illegal Code Error
Select whether to detect illegal code errors.
OFF / ON
• Frequency Error
Select whether to detect frequency deviation errors.
Even when this is set to OFF, the frequency deviation is still shown in the status display.
OFF / ON
• Cable Error
Select whether to detect cable errors.
Even when this is set to OFF, the cable length is still shown in the status display.
OFF / ON
• 12G Cable Error / Warning
Set the upper cable error limit and the upper cable warning limit for 12G input signals. If
the value on the left side is exceeded, an error will occur, and the measured value on the
status display will be displayed in red.
If the value on the right side is exceeded, a warning will occur, and the measured value on
the status display will be displayed in yellow.
The cable used in cable length measurement is L-5.5CUHD.
10 – 80 m
• 3G Cable
Select the cable to use for cable length measurements when the input signal is 3G.
LS-5CFB / 1694A
• 3G Cable Error / Warning
Set the upper cable error limit and the upper cable warning limit for 3G input signals. If
the value on the left side is exceeded, an error will occur, and the measured value on the
status display will be displayed in red.
If the value on the right side is exceeded, a warning will occur, and the measured value on
the status display will be displayed in yellow.
10 - 100 m
