16. Status Display
342
• Area
Specify the percentage of the active picture area over which errors must occur to be
recognized as an error. You cannot configure this setting when Gamut Error is set to OFF.
0.0 - 1.0 - 5.0%
• Duration
Set the number of consecutive video frames over which errors must occur to be
recognized as an error. You cannot configure this setting when Gamut Error is set to OFF.
1 - 60 Frames
• Composite Gamut Error
Select whether to detect composite gamut errors.
ON / OFF
• Setup
Select the setup level to add when converting component signals to composite signals.
0%: No setup level is added.
7.5%: A setup level of 7.5 % is added.
• Composite Upper
Set the composite gamut error upper limit. An error occurs when the input signal level
exceeds the specified value.
In the 5-bar CMP display, levels that are greater than or equal to the specified value are
displayed in red.
90.0 - 135.0%
• Composite Lower
Set the composite gamut error lower limit. An error occurs when the input signal level
goes below the specified value.
In the 5-bar CMP display, levels that are less than or equal to the specified value are
displayed in red.
-40.0 - 20.0%
• Area
Specify the percentage of the active picture area over which errors must occur to be
recognized as an error. You cannot configure this setting when Composite Gamut Error is
set to OFF.
0.0 - 1.0 - 5.0%
