16. Status Display
347
• Time Display
The time is displayed in the format specified by Time that you select by pressing SYS →
F•2 SYSTEM SETUP.
• Channel display
The input channel is displayed.
A “-” is displayed for audio events detected by SER20.
• Format Display
The input format is displayed.
If there is no input signal, “NO SIGNAL” is displayed.
• Event Display
Events are displayed one line at a time in rectangular frames. In the frame, the event
occurrence state is shown for the number that you selected with the function dial (F•D).
Further, for audio events detected by SER20, the corresponding channels are shown.
The colors are used in frames to indicate different states. Gray indicates not applicable for
counting. White indicates no event. Red indicates that an event is occurring. Green
indicates that an event occurred in the past (not occurring currently).
The events that are displayed in the event log are listed below.
Of the items listed below, only those whose detection settings have been set to ON on the
SDI IN SETUP2 tab of the SYS menu, GAMUT COLOR LOG and MAX FALL/CLL ERROR of
the PIC menu, STATUS SETUP of the STATUS menu, ERROR SETUP of the EYE menu, and
ERROR SETUP of the AUDIO menu are displayed.
Table 16-2 Events
