16. Status Display
349
Model/Option
Event Name
(in frame)
Event Name
(one line display)
Description
Level C
Level C
Chroma Error
Level C ST1
Level C ST1
Chroma Error Stream 1
Level C ST2
Level C ST2
Chroma Error Stream 2
Audio BCH
Audio BCH
Embedded Audio BCH Error(Except SD)
Audio Parity
Audio Parity
Embedded Audio Parity Error(Except
SD)
Audio DBN
Audio DBN
Embedded Audio DBN Error
Audio Inhibit
Audio Inhibit
Embedded Audio Inhibit Line Error
Audio Sample
Audio Sample
Embedded Audio Sample Count Error
Frequency
Frequency
Frequency Error
Format Alarm
Format Alarm
Format Alarm
Max Fall
MAX FALL
MAX FALL Error
Max Fall ST1
MAX FALL ST1
MAX FALL Error Stream 1
Max Fall ST2
MAX FALL ST2
MAX FALL Error Stream 2
Max Cll
MAX CLL
MAX CLL Error
Max Cll ST1
MAX CLL ST1
MAX CLL Error Stream 1
Max Cll ST2
MAX CLL ST2
MAX CLL Error Stream 2
LV5300/LV5300A/LV7300-SER02
(other than 12G)
LV5300/LV5300A+SER28/
LV7300-SER02+SER28 (12G)
EYE Jitter
EYE 12G Jitter
12G Jitter Error
EYE 6G Jitter
6G Jitter Error
EYE 3G Jitter
3G Jitter Error
EYE HD Jitter
HD Jitter Error
EYE SD Jitter
SD Jitter Error
EYE T Jitter
EYE 12G T Jitter
12G Timing Jitter Error
EYE 6G T Jitter
6G Timing Jitter Error
EYE 3G T Jitter
3G Timing Jitter Error
EYE HD T Jitter
HD Timing Jitter Error
EYE SD T Jitter
SD Timing Jitter Error
EYE Tr_Tf
EYE 12G Tr_Tf
12G Deltatime Error(Tr-Tf)
EYE 6G Tr_Tf
6G Deltatime Error(Tr-Tf)
EYE 3G Tr_Tf
3G Deltatime Error(Tr-Tf)
EYE HD Tr_Tf
HD Deltatime Error(Tr-Tf)
EYE SD Tr_Tf
SD Deltatime Error(Tr-Tf)
EYE Tf
EYE 12G Tf
12G Falltime Error
EYE 6G Tf
6G Falltime Error
EYE 3G Tf
3G Falltime Error
EYE HD Tf
HD Falltime Error
EYE SD Tf
SD Falltime Error
EYE Tr
EYE 12G Tr
12G Risetime Error
EYE 6G Tr
6G Risetime Error
EYE 3G Tr
3G Risetime Error
EYE HD Tr
HD Risetime Error
EYE SD Tr
SD Risetime Error
EYE Amp.
EYE 12G Amp.
12G Amplitude Error
EYE 6G Amp.
6G Amplitude Error
EYE 3G Amp.
3G Amplitude Error
EYE HD Amp.
HD Amplitude Error
EYE SD Amp.
SD Amplitude Error
EYE Or
EYE 12G Or
12G OverShoot Rising Error
EYE 6G Or
6G OverShoot Rising Error
EYE 3G Or
3G OverShoot Rising Error
EYE HD Or
HD OverShoot Rising Error
EYE SD Or
SD OverShoot Rising Error
EYE Of
EYE 12G Of
12G OverShoot Falling Error
EYE 6G Of
6G OverShoot Falling Error
EYE 3G Of
3G OverShoot Falling Error
