17. Eye Pattern Display (LV5300/LV5300A/LV7300-SER02)
409
• Amplitude Error
Turns the eye pattern's amplitude error detection on and off.
You cannot set Lower to a value that is greater than Upper, even if the value is within the
selectable range.
Upper: 80 - 110 - 140% (640 - 1120 mV)
Lower: 40 - 90 - 100% (320 - 800 mV)
• Risetime Error
Turns the eye pattern's rise time (the time for the signal to rise from 20 to 80 % of its
amplitude) error detection on and off.
Max: 40 - 100 - 140% (54.0 - 189.0 ps)
• Falltime Error
Turns the eye pattern's fall time (the time for the signal to fall from 80 to 20 % of its
amplitude) error detection on and off.
Max: 40 - 100 - 140% (54.0 - 189.0 ps)
• Deltatime Error(Tr-Tf)
Turns the eye pattern's time difference (between the rise and fall times) error detection on
and off. When the measured values exceed the specified value, Tr and Tf are displayed in
red.
Max: 40 - 100 - 140% (20 - 70 ps)
• Timing Jitter Error
Turns the eye pattern and jitter's timing jitter error detection on and off.
Max: 10 - 100 - 200% (0.20 - 4.00 UI, 67.4 - 1348.0 ps)
• Jitter Error
Turns jitter error detection for eye pattern and jitter.
Max: 10 - 100 - 200% (0.03 - 0.60 UI, 10.1 - 202.5 ps)
• Overshoot Rising Error
Turns the rising edge overshoot error detection on and off.
Max: 0 - 100 - 200% (0.0 - 20.0%)
• Overshoot Falling Error
Turns the falling edge overshoot error detection on and off.
Max: 0 - 100 - 200% (0.0 - 20.0%)
