19. Network Control
456
WO
EYE
None
-
EYE:MODE
EYE / JITTER / ?
-
EYE:EYE:INTEN
-128 to 127 / ?
-
EYE:EYE:COLOR
WHITE / YELLOW / CYAN / GREEN / MAGENTA /
RED / BLUE / ?
-
EYE:EYE:SCALE:INTEN
-8 to 7 / ?
-
EYE:EYE:SCALE:COLOR
WHITE / YELLOW / CYAN / GREEN / MAGENTA /
RED / BLUE / ?
-
EYE:EYE:SETUP:GAIN:VAR
CAL / VAR / ?
-
EYE:EYE:SETUP:GAIN:VAL
50 to 200 / ?
-
EYE:EYE:SETUP:SWEEP
2UI / 4UI / 16UI / ?
-
EYE:EYE:SETUP:FILTER
100kHZ / 10KHZ / 1KHZ / 100HZ / 10HZ / TIMING
/ ALIGNMENT / ?
-
EYE:EYE:SETUP:TILE
SINGLE / DUAL / ?
-
EYE:EYE:SETUP:CURSOR
ON / OFF / ?
WO
EYE:EYE:SETUP:CURSOR:RESET
None
-
EYE:EYE:SETUP:CURSOR:XY_SEL
X / Y / TR_TF / ?
-
EYE:JIT:INTEN
-128 to 127 / ?
-
EYE:JIT:COLOR
WHITE / YELLOW / CYAN / GREEN / MAGENTA /
RED / BLUE / ?
-
EYE:JIT:SCALE:INTEN
-8 to 7 / ?
-
EYE:JIT:SCALE:COLOR
WHITE / YELLOW / CYAN / GREEN / MAGENTA /
RED / BLUE / ?
-
EYE:JIT:SETUP:GAIN_SWEEP:MAG
X1 / X2 / X8 / ?
-
EYE:JIT:SETUP:GAIN_SWEEP:12G:MAG
X1 / X2 / X4 / X16 / ?
-
EYE:JIT:SETUP:GAIN_SWEEP:SWEEP
1H / 2H / 1V / 2V / ?
-
EYE:JIT:SETUP:FILTER
100kHZ / 10KHZ / 1KHZ / 100HZ / 10HZ / TIMING
/ ALIGNMENT / ?
-
EYE:JIT:SETUP:PEAK_HOLD
ON / OFF / ?
WO
EYE:JIT:SETUP:PEAK_CLEAR
None
-
EYE:JIT:SETUP:TILE
SINGLE / DUAL / ?
-
EYE:JIT:SETUP:CURSOR
ON / OFF / ?
WO
EYE:JIT:SETUP:CURSOR:RESET
None
-
EYE:JIT:SETUP:CURSOR:XY_SEL
X / Y / ?
WO
EYE:ERROR:SETUP:COMPLETE
None
-
EYE:ERROR:12G:AMP
ON / OFF / ?
-
EYE:ERROR:12G:AMP:UPPER
80 to 140 / ?
-
EYE:ERROR:12G:AMP:LOWER
40 to 100 / ?
-
EYE:ERROR:12G:RISE
ON / OFF / ?
-
EYE:ERROR:12G:RISE:MAX
40 to 110 / ?
-
EYE:ERROR:12G:FALL
ON / OFF / ?
-
EYE:ERROR:12G:FALL:MAX
40 to 110 / ?
-
EYE:ERROR:12G:DELTA
ON / OFF / ?
-
EYE:ERROR:12G:DELTA:MAX
40 to 110 / ?
-
EYE:ERROR:12G:TIMING_JIT
ON / OFF / ?
-
EYE:ERROR:12G:TIMING_JIT:MAX
10 to 200 / ?
-
EYE:ERROR:12G:CURRENT_JIT
ON / OFF / ?
-
EYE:ERROR:12G:CURRENT_JIT:MAX
10 to 200 / ?
-
EYE:ERROR:12G:OVERSHOOT_RISE
ON / OFF / ?
-
EYE:ERROR:12G:OVERSHOOT_RISE:MAX
0 to 200 / ?
-
EYE:ERROR:12G:OVERSHOOT_FALL
ON / OFF / ?
-
EYE:ERROR:12G:OVERSHOOT_FALL:MAX
0 to 200 / ?
-
EYE:ERROR:6G:AMP
ON / OFF / ?
-
EYE:ERROR:6G:AMP:UPPER
80 to 140 / ?
-
EYE:ERROR:6G:AMP:LOWER
40 to 100 / ?
-
EYE:ERROR:6G:RISE
ON / OFF / ?
-
EYE:ERROR:6G:RISE:MAX
40 to 110 / ?
