• l40pictureTBL(5) group
MIB
OID
SYNTAX
ACCESS
VALUE/RANGE
l40pictureConfigTBL
l40pictureTBL.1
Aggregate
-
-
l40pictureMode
l40pictureConfigTBL.1
INTEGER
R/W
1 = fit
2 = real
3 = x2
4 = full
l40pictureAdjustTBL
l40pictureConfigTBL.2
Aggregate
-
-
l40pictureAdjustColor
l40pictureAdjustTBL.1
INTEGER
R/W
1 = color
2 = mono
l40pictureChroma
l40pictureAdjustTBL.2
INTEGER
R/W
1 = normal
2 = up
l40pictureBrightness
l40pictureAdjustTBL.3
DisplayString
R/W
-50.0 to 50.0
l40pictureContrast
l40pictureAdjustTBL.4
DisplayString
R/W
0 to 200.0
l40pictureGainR
l40pictureAdjustTBL.5
DisplayString
R/W
0 to 200.0
l40pictureGainG
l40pictureAdjustTBL.6
DisplayString
R/W
0 to 200.0
l40pictureGainB
l40pictureAdjustTBL.7
DisplayString
R/W
0 to 200.0
l40pictureGainChroma
l40pictureAdjustTBL.8
DisplayString
R/W
0 to 200.0
l40pictureBiasR
l40pictureAdjustTBL.9
DisplayString
R/W
-50.0 to 50.0
l40pictureBiasG
l40pictureAdjustTBL.10
DisplayString
R/W
-50.0 to 50.0
l40pictureBiasB
l40pictureAdjustTBL.11
DisplayString
R/W
-50.0 to 50.0
l40pictureDispGamut
l40pictureConfigTBL.3
INTEGER
R/W
1 = off
2 = white
3 = red
4 = mesh
l40pictureDispStatusInfo
l40pictureConfigTBL.4
INTEGER
R/W
1 = off
2 = on
l40pictureDispPosH
l40pictureConfigTBL.6
INTEGER
R/W
-32768 to 32767
l40pictureDispPosV
l40pictureConfigTBL.7
INTEGER
R/W
-32768 to 32767
l40pictureMarkerTBL
l40pictureConfigTBL.8
Aggregate
-
-
l40pictureMarkerFrame
l40pictureMarkerTBL.1
INTEGER
R/W
1 = off
2 = on
l40pictureMarkerCenter
l40pictureMarkerTBL.2
INTEGER
R/W
1 = off
2 = on
l40pictureMarkerAspect
l40pictureMarkerTBL.3
INTEGER
R/W
1 = off
2 = asp-17x9
3 = asp-16x9
4 = asp-14x9
5 = asp-13x9
6 = asp-4x3
7 = asp-239x1
8 = asp-afd
l40pictureAspectShadow
l40pictureMarkerTBL.4
INTEGER
R/W
0 to 100
l40pictureSafeAction
l40pictureMarkerTBL.5
INTEGER
R/W
1 = off
2 = arib
3 = smpte
4 = user
l40pictureSafeTitle
l40pictureMarkerTBL.6
INTEGER
R/W
1 = off
2 = arib
3 = smpte
4 = user
l40pictureSafeUser1Width
l40pictureMarkerTBL.7
INTEGER
R/W
0 to 100
l40pictureSafeUser1Height
l40pictureMarkerTBL.8
INTEGER
R/W
0 to 100
l40pictureSafeUser2Width
l40pictureMarkerTBL.9
INTEGER
R/W
0 to 100
l40pictureSafeUser2Height
l40pictureMarkerTBL.10
INTEGER
R/W
0 to 100
l40pictureSafeUserAspect
l40pictureMarkerTBL.11
INTEGER
R/W
1 = off
2 = on
