5. BEFORE YOU BEGIN MEASURING
71
• Tab Screen Settings
Click or tap the setting on the screen and the function menu.
You can change a value on a tab screen by using the ▲▼ key to the left and right of FD or
the mouse wheel.
• Moving Cursors
Cursors on video signal waveforms can be moved easily with a mouse or touch panel.
When using a mouse, click a cursor to select it, and then click a position to move the
cursor. To unselect, right-click. A portion of the cursors can be moved with a mouse
wheel. If you use a mouse wheel, right-click to set the position.
When using the touch panel, tap a cursor to select it, and then tap a position to move the
cursor.
• Right-Click Menu
Right-click the mouse or click or tap RIGHT CLICK at the upper left of the screen to display
the following menu.
LAYOUT and ENHANCED LAYOUT are an item that can only be set using the mouse or
touch panel.
Table 5-6 Right-click menu
Menu
Description
ALL CLEAR
Hides the keys and function menu from the screen.
Click in the screen to redisplay them.
KEY CLEAR
Hides the keys from the screen.
Click in the screen to redisplay them.
MENU CLEAR
Hides the function menu.
Click in the screen to redisplay it.
LAYOUT
Creates a measurement screen layout.
[See also] 6.5, “Customized Layout (SER26)”
ENHANCED LAYOUT
Creates a measurement screen layout.
This option can be selected in simul mode.
[See also] 6.6, “Enhanced Layout (SER26)”
