D9.6 TRCBBCTLR, Branch Broadcast Control Register

The TRCBBCTLR controls how branch broadcasting behaves, and allows branch broadcasting to be

enabled for certain memory regions.

Bit field descriptions

The TRCAUXCTLR is a 32-bit register.

31 08 7

RANGE

MODE

RES0

Figure D9-5 TRCBBCTLR bit assignments

RES0, [31:9]

RES0 Reserved.

MODE, [8]

Mode bit:

0 Exclude mode. Branch broadcasting is not enabled in the address range that RANGE

defines.

If RANGE==0 then branch broadcasting is enabled for the entire memory map.

1 Include mode. Branch broadcasting is enabled in the address range that RANGE

defines.

If RANGE==0 then the behavior of the trace unit is constrained UNPREDICTABLE. That

is, the trace unit might or might not consider any instructions to be in a branch

broadcast region.

RANGE, [7:0]

Address range field.

Selects which address range comparator pairs are in use with branch broadcasting. Each bit

represents an address range comparator pair, so bit[n] controls the selection of address range

comparator pair n. If bit[n] is:

0 The address range that address range comparator pair n defines, is not selected.

1 The address range that address range comparator pair n defines, is selected.

Bit fields and details not provided in this description are architecturally defined. See the Arm

Architecture Reference Manual Armv8, for Armv8-A architecture profile.

The TRCBBCTLR can be accessed through the external debug interface, offset 0x03C.

D9 ETM registers

D9.6 TRCBBCTLR, Branch Broadcast Control Register

reserved.

D9-505

Non-Confidential
