B2.95 TCR_EL3, Translation Control Register, EL3

The TCR_EL3 controls translation table walks required for stage 1 translation of memory accesses from

EL3 and holds cacheability and shareability information for the accesses.

Bit field descriptions

TCR_EL3 is a 32-bit register and is part of the Virtual memory control registers functional group.

31 30 24 23 22 21 20 19 18 16 15 14 13 12 11 10 9 8 7 6 5

SH0TG0PS0

IRGN0

ORGN0

T0SZ

TBI

29 28 25

HPD

RES0

RES1

27 26

HWU59

HWU60

HWU61

HWU62

Figure B2-79 TCR_EL3 bit assignments

Note

Bits[28:21], architecturally defined, are implemented in the core.

HD, [22]

Dirty bit update. The possible values are:

0 Dirty bit update is disabled.

1 Dirty bit update is enabled.

HA, [21]

Stage 1 Access flag update. The possible values are:

0 Stage 1 Access flag update is enabled.

1 Stage 1 Access flag update is disabled.

Configurations

There are no configuration notes.

Bit fields and details that are not provided in this description are architecturally defined. See the

Arm

Architecture Reference Manual Armv8, for Armv8-A architecture profile.

B2 AArch64 system registers

B2.95 TCR_EL3, Translation Control Register, EL3

reserved.

B2-280

Non-Confidential
