A5.1 About the MMU
The Memory Management Unit (MMU) is responsible for translating addresses of code and data Virtual
Addresses (VA) to Physical Addresses (PAs) in the real system. The MMU also controls memory access
permissions, memory ordering, and cache policies for each region of memory.
A5.1.1 Main functions
The three main functions of the MMU are to:
• Control the table walk hardware that accesses translation tables in main memory.
• Translate Virtual Addresses (VAs) to Physical Addresses (PAs).
• Provide fine-grained memory system control through a set of virtual-to-physical address mappings
and memory attributes that are held in translation tables.
Each stage of address translation uses a set of address translations and associated memory properties that
are held in memory mapped tables called translation tables. Translation table entries can be cached into a
Translation Lookaside Buffer (TLB).
The following table describes the components included in the MMU.
Table A5-1 TLBs and TLB caches in the MMU
Component Description
Instruction L1 TLB 48 entries, fully associative.
Data L1 TLB 48 entries, fully associative.
L2 TLB cache 1280 entries, 5-way set associative.
Translation table prefetcher Detects access to contiguous translation tables and prefetches the next one. This prefetcher can be
disabled in the ECTLR register.
The TLB entries contain either one or both of a global indicator and an Address Space Identifier (ASID)
to permit context switches without requiring the TLB to be invalidated.
The TLB entries contain a Virtual Machine Identifier (VMID) to permit virtual machine switches by the
hypervisor without requiring the TLB to be invalidated.
A5.1.2 AArch64 behavior
The Cortex-A76 core is an Armv8 compliant core that supports execution in AArch64 state.
The following table shows the AArch64 behavior.
Table A5-2 AArch64 behavior
AArch64
Address translation
system
The Armv8 address translation system resembles an extension to the Long descriptor format address
translation system to support the expanded virtual and physical address space.
Translation granule 4KB, 16KB, or 64KB for Armv8 Virtual Memory System Architecture (VMSA)
ASID size 8 or 16 bits depending on the value of TCR_ELx.AS.
VMID size 8 or 16 bits depending on the value of VTCR_EL2.VS.
PA size
Maximum 40 bits.
Any configuration of TCR_ELx.IPS over 40 bits is considered as 40 bits. You can enable or disable each
stage of the address translation independently.
A5 Memory Management Unit
A5.1 About the MMU
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
A5-62
Non-Confidential

ARM Cortex-A76 Core Specifications

General

Architecture	ARMv8.2-A
Microarchitecture	Cortex-A76
Pipeline Depth	13 stages
Frequency	Up to 3.0 GHz
Process Technology	7nm
Core Type	Out-of-order
NEON	Yes
Power Efficiency	Improved over Cortex-A75
Performance Improvement	35% over Cortex-A75
Core Count	1-4 cores per cluster
ISA Support	AArch64 and AArch32
Branch Prediction	Yes
L1 Data Cache	32KB, per core
L2 Cache	256KB or 512KB, per core
L3 Cache	Up to 4MB
Memory Support	LPDDR4, LPDDR4X, DDR4
DynamIQ Shared Unit (DSU)	DynamIQ Shared Unit (DSU)
Cryptography Extensions	Yes
Virtualization Support	Yes
L1 Cache	64 KB per core
