ARM Cortex-A76 Core User Manual

B2.67 ID_ISAR2_EL1, AArch32 Instruction Set Attribute Register 2, EL1
The ID_ISAR2_EL1 provides information about the instruction sets implemented by the core in
AArch32.
Bit field descriptions
ID_ISAR2_EL1 is a 32-bit register, and is part of the Identification registers functional group.
This register is Read Only.
31 28 27 24 23 20 19 16 15 12 11 8 7 4 3 0
MultiAccessInt
Reversal PSR_AR MultU MultS Mult MemHint LoadStore
Figure B2-51 ID_ISAR2_EL1 bit assignments
Reversal, [31:28]
Indicates the implemented Reversal instructions:
0x2 The REV, REV16, REVSH, and RBIT instructions.
PSR_AR, [27:24]
Indicates the implemented A and R profile instructions to manipulate the PSR:
0x1 The MRS and MSR instructions, and the exception return forms of data-processing
instructions.
The exception return forms of the data-processing instructions are:
• In the A32 instruction set, data-processing instructions with the PC as the destination and the
S bit set.
• In the T32 instruction set, the SUBSPC, LR, #N instruction.
MultU, [23:20]
Indicates the implemented advanced unsigned Multiply instructions:
0x2 The UMULL, UMLAL, and UMAAL instructions.
MultS, [19:16]
Indicates the implemented advanced signed Multiply instructions.
0x3 • The SMULL and SMLAL instructions.
• The SMLABB, SMLABT, SMLALBB, SMLALBT, SMLALTB, SMLALTT, SMLATB, SMLATT,
SMLAWB, SMLAWT, SMULBB, SMULBT, SMULTB, SMULTT, SMULWB, SMULWT instructions,
and the Q bit in the PSRs.
• The SMLAD, SMLADX, SMLALD, SMLALDX, SMLSD, SMLSDX, SMLSLD, SMLSLDX, SMMLA,
SMMLAR, SMMLS, SMMLSR, SMMUL, SMMULR, SMUAD, SMUADX, SMUSD, and SMUSDX
instructions.
Mult, [15:12]
Indicates the implemented additional Multiply instructions:
0x2 The MUL, MLA and MLS instructions.
MultiAccessInt, [11:8]
Indicates the support for interruptible multi-access instructions:
B2 AArch64 system registers
B2.67 ID_ISAR2_EL1, AArch32 Instruction Set Attribute Register 2, EL1
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
B2-237
Non-Confidential

ARM Cortex-A76 Core Specifications

General

Architecture	ARMv8.2-A
Microarchitecture	Cortex-A76
Pipeline Depth	13 stages
Frequency	Up to 3.0 GHz
Process Technology	7nm
Core Type	Out-of-order
NEON	Yes
Power Efficiency	Improved over Cortex-A75
Performance Improvement	35% over Cortex-A75
Core Count	1-4 cores per cluster
ISA Support	AArch64 and AArch32
Branch Prediction	Yes
L1 Data Cache	32KB, per core
L2 Cache	256KB or 512KB, per core
L3 Cache	Up to 4MB
Memory Support	LPDDR4, LPDDR4X, DDR4
DynamIQ Shared Unit (DSU)	DynamIQ Shared Unit (DSU)
Cryptography Extensions	Yes
Virtualization Support	Yes
L1 Cache	64 KB per core
