B2.86 PAR_EL1, Physical Address Register, EL1
The PAR_EL1 returns the output address from an address translation instruction that executed
successfully, or fault information if the instruction did not execute successfully.
Bit field descriptions, PAR_EL1.F is 0
The following figure shows the PAR bit assignments when PAR.F is 0.
63 067 112
PA
LPAE
NS
891011
IMP DEF
FSH
39405556
ATTR
RES0
Figure B2-70 PAR bit assignments, PAR_EL1.F is 0
IMP DEF, [10]
IMPLEMENTATION DEFINED. Bit[10] is RES0.
F, [0]
Indicates whether the instruction performed a successful address translation.
0 Address translation completed successfully.
1 Address translation aborted.
Configurations
There are no configuration notes.
Bit fields and details that are not provided in this description are architecturally defined. See the
Arm
®
Architecture Reference Manual Armv8, for Armv8-A architecture profile.
Bit field descriptions, PAR_EL1.F is 1
See the Arm
®
Architecture Reference Manual Armv8, for Armv8-A architecture profile.
