ARM Cortex-A76 Core User Manual

D9.15 TRCCLAIMSET, Claim Tag Set Register
The TRCCLAIMSET sets bits in the claim tag and determines the number of claim tag bits implemented.
Bit field descriptions
The TRCCLAIMSET is a 32-bit register.
31 4 3 0
SET
RES0
Figure D9-14 TRCCLAIMSET bit assignments
RES0, [31:4]
RES0 Reserved.
SET, [3:0]
On reads, for each bit:
0 Claim tag bit is not implemented.
1 Claim tag bit is implemented.
On writes, for each bit:
0 Has no effect.
1 Sets the relevant bit of the claim tag.
Bit fields and details not provided in this description are architecturally defined. See the Arm
®
Architecture Reference Manual Armv8, for Armv8-A architecture profile.
The TRCCLAIMSET can be accessed through the external debug interface, offset 0xFA0.
D9 ETM registers
D9.15 TRCCLAIMSET, Claim Tag Set Register
