ARM Cortex-A76 Core

To Next Page

To Previous Page

B2.104 VTTBR_EL2, Virtualization Translation Table Base Register, EL2

VTTBR_EL2 holds the base address of the translation table for the stage 2 translation of memory

accesses from Non-secure EL0 and EL1.

Bit field descriptions

VTTBR_EL2 is a 64-bit register.

63 0

RES0

CnP

BADDR

44748

VMID

Figure B2-87 VTTBR_EL2 bit assignments

CnP, [0]

Common not Private. The possible values are:

0 CnP is not supported.

1 CnP is supported.

Configurations

There are no configuration notes.

Bit fields and details not provided in this description are architecturally defined. See the Arm

Architecture Reference Manual Armv8, for Armv8-A architecture profile.

B2 AArch64 system registers

B2.104 VTTBR_EL2, Virtualization Translation Table Base Register, EL2

reserved.

B2-289

Non-Confidential
