ARM Cortex-A76 Core User Manual

B2.94 TCR_EL2, Translation Control Register, EL2
The TCR_EL2 controls translation table walks required for stage 1 translation of a memory access from
EL2 and holds cacheability and shareability information.
Bit field descriptions
TCR_EL2 is a 32-bit register.
TCR_EL2 is part of:
• The Virtual memory control registers functional group.
• The Hypervisor and virtualization registers functional group.
31 30 24 23 22 21 20 19 18 16 15 14 13 12 11 10 9 8 7 6 5
0
SH0TG0PS
IRGN0
ORGN0
T0SZ
TBI
HA
HD
HPD
252829
HWU62-59
RES0
RES1
Figure B2-78 TCR_EL2 bit assignments
Note
Bits[28:21], architecturally defined, are implemented in the core.
HD, [22]
Dirty bit update. The possible values are:
0 Dirty bit update is disabled.
1 Dirty bit update is enabled.
HA, [21]
Stage 1 Access flag update. The possible values are:
0 Stage 1 Access flag update is enabled.
1 Stage 1 Access flag update is disabled.
Configurations
When the Virtualization Host Extension is activated, TCR_EL2 has the same bit assignments as
TCR_EL1.
Bit fields and details that are not provided in this description are architecturally defined. See the
Arm
®
Architecture Reference Manual Armv8, for Armv8-A architecture profile.
B2 AArch64 system registers
B2.94 TCR_EL2, Translation Control Register, EL2
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
B2-279
Non-Confidential

ARM Cortex-A76 Core Specifications

General

Architecture	ARMv8.2-A
Microarchitecture	Cortex-A76
Pipeline Depth	13 stages
Frequency	Up to 3.0 GHz
Process Technology	7nm
Core Type	Out-of-order
NEON	Yes
Power Efficiency	Improved over Cortex-A75
Performance Improvement	35% over Cortex-A75
Core Count	1-4 cores per cluster
ISA Support	AArch64 and AArch32
Branch Prediction	Yes
L1 Data Cache	32KB, per core
L2 Cache	256KB or 512KB, per core
L3 Cache	Up to 4MB
Memory Support	LPDDR4, LPDDR4X, DDR4
DynamIQ Shared Unit (DSU)	DynamIQ Shared Unit (DSU)
Cryptography Extensions	Yes
Virtualization Support	Yes
L1 Cache	64 KB per core
