ARM Cortex-A76 Core User Manual

D9.21 TRCDEVAFF0, Device Affinity Register 0
The TRCDEVAFF0 provides an additional core identification mechanism for scheduling purposes in a
cluster. TRCDEVAFF0 is a read-only copy of MPIDR accessible from the external debug interface.
Bit field descriptions
The TRCDEVAFF0 is a 32-bit register.
31 30 29 8 7 0
U Aff2 Aff0
25 24
MT
23
Aff1
16 15
RES0
RES1
Figure D9-20 TRCDEVAFF0 bit assignments
RES1, [31]
RES1 Reserved.
U, [30]
Indicates a single core system, as distinct from core 0 in a cluster. This value is:
0 Core is part of a multiprocessor system. This is the value for implementations with
more than one core, and for implementations with an ACE or CHI master interface.
1 Core is part of a uniprocessor system. This is the value for single core
implementations with an AXI master interface.
RES0, [29:25]
RES0 Reserved.
MT, [24]
Indicates whether the lowest level of affinity consists of logical cores that are implemented
using a multithreading type approach. This value is:
0 Performance of cores at the lowest affinity level is largely independent.
Aff2, [23:16]
Affinity level 2. Second highest level affinity field.
Indicates the value read in the CLUSTERIDAFF2 configuration signal.
Aff1, [15:8]
Affinity level 1. Third highest level affinity field.
Indicates the value read in the CLUSTERIDAFF1 configuration signal.
Aff0, [7:0]
Affinity level 0. Lowest level affinity field.
Indicates the core number in the Cortex-A76 core. The possible values are:
0x0 A cluster with one core only.
0x0, 0x1 A cluster with two cores.
0x0, 0x1, 0x2 A cluster with three cores.
D9 ETM registers
D9.21 TRCDEVAFF0, Device Affinity Register 0
100798_0300_00_en Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
D9-524
Non-Confidential
